Stainless Steel Pipe Bending Machine

Product Description

Specification:

Material / Metal Processed:Brass / Copper, Stainless steel, Aluminum

Bending Radius (mm):Max Bending Angle (Deg) 190

Bending Precision (Deg): 1

Extra Services:Welding / Brazing

Bending diameter range:0-500

Power (kW):4

Weight (KG):1500

Applicable Industries:Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction works , Advertising Company

Machine feature:

1.This machine can be operated simple and clear by touch screen.

2.This machine equips pneumatic system and complies with environmental protection with high stability and cost -efficient.

3.Automatic recognize the work piece , slow returning core with slow rate but quickly working in process. material is boosted by a trolley that can improve the appearance of angle.

4.Touch screen operation, computer numerical control.

5.graphical programming system: drawing and modifying the three-dimensional drawing on the screen, makes the program operation simple, quick and correct.

6.Rebound test: comparison test for the features of batches of pipes.

7.Single-step debugging function: a careful observation on the deformation of the pipe from  the trial manufacture of dies.

8.Automatic drawing of the graphics of dies: observably  help to develop new products.

9. Over-all inspection: hydraulic/electrical circuit/ driving systems, absence of phase /inversion, voltage, temperature, oil pressure, and automatically diagnose the troubles.other data such as passwords, keys, working hours/ quantities recording are applied to manufacturing management.
